Installation And Maintenance Of Mud Mixer

How to install a maintenance Mud Agitators? The Mud Agitator Supplier will tell you

1. When installing the slurry agitator, horizontally lift the agitator and place it in the position to be installed smoothly. After adjusting the coaxiality <0.39mm, weld the four M16 holes to the tank and tighten the base fixing bolts. .

2. The rigid coupling of the mud agitator must be equipped with a spring pad and should be firm and reliable, otherwise it will cause the yaw of the pulsator shaft and aggravate the wear of the reducer.

3. The mud stirrer stirrer should have no abnormal noise, such as abnormal noise, high temperature and high temperature. Otherwise, stop the inspection and troubleshoot.

4. The height of the oil level of the mud agitator reducer should be kept at the middle position of the oil window, and the lubricating oil is often replenished during work. It is recommended to use 120# industrial gear oil. Other lubricants of appropriate particle size may also be used when the site is not satisfactory.
