CBM (is short for coalbed methane) mud circulation system can effective control the solid phase content in the mud. The solid phase content in the mud can be controlled within 5 micron -15 microns.
Meanwhile also can do mud parameter matching, improve the drilling mud quality, the mud viscosity can be up to 120s, mud specific gravity can get to 2.4g/cm³, otherwise also can improve drilling speed , extend the service life of mud pump and drill rig to ensure the drilling safety, reduce the operating strength of the operator. It can also improve the environment of the drilling site and play an environmental role.
Model | Treating capacity (m³/h) | Separation point d50(μm) | Dimension (m) | Total power (kw) | Weight (kg) |
DCRS60 | 60 | 15-44 | 4.0×3.8×2.84 | 18 | 3000 |
